OTW GNSS Module GPS QZSS GLONASS 1Hz-18Hz High Gain Patch

Product Categories

Shenzhen Anzewei Technology Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Place of Origin : China

Model Number : WT-2828-UB

MOQ : 1

Price : $7.98-9.88

Type : GNSS Module

Country of Origin : CHINA

Brand : OTW

Chipset : XX

Application : Positioning, surveying and mapping, etc

Operating mode : GPS/QZSS+GLONASS

Output Mode : UART/TTL/R232/USB

Baud rate : 4800bps-921600bps,Default115200bps

NMEA messages : RMC,VTG,GGA,GSA,GSV,GLL

Update frequency : 1Hz-18Hz(default 1Hz)

Voltage : 3.0V to 5.0V

Power consumption : 35 mA @3.3V

Size : 28.3mm*28.3mm*7.5mm

Contact Now

GPS Antenna Integrated High Gain Patch Positioning Module Receiver Type QZSS GLONASS GNSS Multiple Specifications Available

Module performance
Model	WT-2828-UB
Receiver type	GPS/QZSS L1 GLONASS L1
Agreement	NMEA-0183 compliant protocol or custom protocol
NMEA messages	RMC,VTG,GGA,GSA,GSV,GLL
Available baud rate	4800bps~921600bps(default 115200bps)
Channel	56
Sensitivity	Tracking -162 dbm Hot start -157dBm Cold start -148dBm
Cold start	Average 29 seconds
Hot start	Average 1 seconds
Accuracy	Horizontal accuracy 2.5m Velocity: 0.1m /s Timepulse signal: RMS 30 ns
Max Height	18000 m
Max Speed	500 m/s
Max Acceleration	≦ 4G
Regeneration frequency	1Hz -18 Hz
Positioning mode	A-GNSS
Port
Port	UART/TTL/R232/USB
Physical property
Type	1.25mm 6pins connector
Size	28.3mm * 28.3mm * 7.5 mm (+/- 0.5mm)
Power supply
Voltage	3V~5V
Power Consume	35mA@3.3V
Oerating Environment
Humidity range	5% to 95% non-condensing
Working Temperature	-40℃ to 85℃
Storage Temperature	-40℃ to 85℃

Product Tags:

18Hz Built In GNSS
