Dual Frequency GNSS Module GPS+GLONASS+GALILEO+BDS 28.3mm

Product Categories

Shenzhen Anzewei Technology Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Place of Origin : China

Model Number : WT-2828-DF

MOQ : 1

Price : $5.40-5.80

Type : GNSS Module

Country of Origin : CHINA

Brand : OTW

Chipset : XX

Application : Positioning, surveying and mapping, etc

Operating mode : GPS+GLONASS+GALILEO+ BDS

Output Mode : UART/TTL/R232/USB

Baud rate : 4800bps-921600bps,Default115200bps

NMEA messages : RMC,VTG,GGA,GSA,GSV,GLL

Update frequency : 0.25Hz-10Hz(default 1Hz)

Voltage : 3.0V to 5.0V

Power consumption : 35 mA @3.3V

Size : 28.3mm*28.3mm*7.5mm

Contact Now

Wireless gps receiver Dual frequency gps module antenna integrated for tracking and positioning

Product attributes

Module performance
Model	WT-2828-DF
Receiver type	BDS:B1I/B1C & B2a GPS/QZSS:L1C/A & L5 GLONASS:L1 Galileo:E1 & E5a
Arithmetic	Integrated dual frequency algorithm
Agreement	NMEA-0183 compliant protocol or custom protocol
NMEA messages	RMC,VTG,GGA,GSA,GSV,GLL
Available baud rate	4800bps~921600bps(default 115200bps)
Channel	128
Sensitivity	Tracking: -167dbm Capture: -160dbm Cold start -148dbm
Cold start	Average 28 seconds
Hot start	Average 1 seconds
Accuracy	<level 2m+1ppm CEP50
Max Height	18000 m
Max Speed	515 m/s
Max Acceleration	≦ 4G
Regeneration frequency	0.25 Hz -10 Hz
Positioning mode	A-GNSS,Double frequency
Port
Port	UART/TTL/R232/USB
Physical property
Type	1.25mm 6pins connector
Size	28.3mm * 28.3mm * 7.5 mm (+/- 0.5mm)
Power supply
Voltage	3V~5V
Power Consume	35mA@3.3V
Oerating Environment
Humidity range	5% to 95% non-condensing
Working Temperature	-40℃ to 85℃
Storage Temperature	-40℃ to 85℃
